Engineered as part of the renowned i9 Trail series, the 1/1 Trail 6-Bolt Rear Wheel delivers the perfect balance of strength and versatility. With a 27mm inner rim width and the dependable 1/1 hub at its core, its built to conquer technical terrain and long rides alike. Whether you’re charging descents or grinding out all-day missions, the 1/1 Trail Rear Wheel is ready for anything.

Industry Nine 1/1 Trail Specs

• Rear Wheel
• Hub
• Rim
• Spoke
• Parts

I9 1/1 Trail Rear Wheel

Model: Industry Nine 1/1 Trail Built For: XC to Aggressive Trail Position: Rear Warranty: 2 Years (Click here for details) Weight: 950 grams (29″) Weight Limit: 250lbs or 113kg max

Wheel is shipped tubeless ready and includes the rim tape and valve installed.

I9 1/1 Hub

Model: Industry Nine 1/1 Rotor Mount: 6-Bolt Holes: 28 hole Points of Engagement: 90 POE Drive Ring: 45 tooth Pawls: 6 Engagement: 4 degrees Bearing: Enduro Material: Aluminum

I9 Trail S Rim

Model: Industry Nine Trail S Tire Width: 2.20″ – 2.50″ Inner Rim Width: 27mm Outer Rim Width: 31mm Valve: 40mm Presta Material: Aluminum Rim Tape: Included & Installed Tubeless Ready: Yes Rim Weight: 455g (29″)

Sapim Race Spoke

Model: Sapim Race 14g Shape: J-Bend Material: Steel Nipple: Sapim alloy double lock Spoke count: 28

1/1 Replacement Parts

Rim: Trail S Rim Freehub: Complete Freehub Kit Bearing: Hub Bearing Kit Bearing Tool Kit: Bearing Tool Kit Axle: Front & Rear Hub Axle EndCaps: Front & Rear EndCaps Pawl: Freehub Pawl Pawl Spring: Freehub Pawl Spring Tubeless Valves: Tubeless Valves
